Product Summary
The SI6433DQ-T1 is a 20V P-Channel PowerTrench MOSFET. It is produced using Fairchild Semiconductor’s advanced PowerTrench process that has been especially tailored to minimize the on-state resistance and yet maintain low gate charge for superior switching performance. The SI6433DQ-T1 is used in Power management, Load switch.
Parametrics
SI6433DQ-T1 absolute maximum ratings: (1)VDSS Drain–Source Voltage: –20 V; (2)VGSS Gate-Source Voltage: ±8 V; (3)ID Drain Current – Continuous: –4.5 A, Pulsed: –40 A; (4)PD Power Dissipation for Single Operation: 1.3 W; (5)TJ, TSTG Operating and Storage Junction Temperature Range: –55 to +150 ℃.
Features
SI6433DQ-T1 features: (1)-4.5 A, -20 V. RDS(ON) = 47 mΩ@ VGS = -4.5 V, RDS(ON) = 65 mΩ@ VGS = -2.5 V, RDS(ON) = 100 mΩ@ VGS = -1.8 V; (2)RDS(ON) rated for use with 1.8 V logic; (3)Low gate charge (13nC typical); (4)High performance trench technology for extremely low RDS(ON); (5)Low profile TSSOP-8 package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SI6433DQ-T1 |
Vishay/Siliconix |
MOSFET 12V 4A 1.5W |
Data Sheet |
Negotiable |
|
||||||||||||
