PS2533L-1-V-F3

optically coupled isolator, 4-DIP, 350 V, 80 mA, PS2533L-1-V-F3

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.40~0.40 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.40~0.40

PartNumber:: PS2533L-1-V-F3

Brand:: Renesas Technology Corp - Renesas | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-04

From Other Seller

Part Number:PS2533L-1-V-F3
US $0.40 - 0.40
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PS2533L-1-V-F3 is an optically coupled isolator containing a GaAs light emitting diode and an NPN silicon darlington connected phototransistor. The PS2533L-1-V-F3 is in a plastic DIP (Dual In-line Package) and the PS2533L-1 is lead bending type (Gull-wing) for surface mount. The applications of the PS2533L-1-V-F3 include: Telephone, Exchange equipment, FAX/MODEM.

Parametrics

PS2533L-1-V-F3 absolute maximum ratings: (1)Reverse Voltage VR: 6 V; (2)Forward Current (DC) IF: 80 mA; (3)Power Dissipation Deratin ΔPD/℃: 1.5 mW/℃; (4)Power Dissipation PD: 150 mW; (5)Peak Forward Current IFP: 1 A; (6)Collector to Emitter Voltage VCEO: 350V; (7)Emitter to Collector Voltage VECO: 0.6 V; (8)Collector Current IC: 150 mA; (9)Isolation Voltage BV: 5 000 Vr.m.s.; (10)Operating Ambient Temperature TA: -55 to +100 ℃; (11)Storage Temperature Tstg: -55 to +150 ℃.

Features

PS2533L-1-V-F3 features: (1)High collector to emitter voltage (VCEO = 350 V); (2)High Isolation voltage (BV = 5 000 Vr.m.s.); (3)High current transfer ratio (CTR = 4 000% TYP.); (4)High-speed switching (tr, tf = 100 μs TYP.); (5)Ordering number of tape product: PS2533L-1-F3: 2 000 pcs/reel; (6)Safety standards.
