Product Summary
The NSTB1002DXV5T1 is a BRT (Bias Resistor Transistor). It contains a single transistor with a monolithic bias network consisting of two resistors; a series base resistor and a base-emitter resistor. The NSTB1002DXV5T1 is designed to replace a single device and its external resistor bias network. The BRT eliminates these individual components by integrating them into a single device.
Parametrics
NSTB1002DXV5T1 absolute maximum ratings: (1)Collector-Base Voltage, VCBO: -40 to 50 Vdc; (2)Collector-Emitter Voltage, VCEO: -40 to 50 Vdc; (3)Collector Current, IC: -200 to 100 mAdc.
Features
NSTB1002DXV5T1 features: (1)Simplifies Circuit Design; (2)Reduces Board Space; (3)Reduces Component Count; (4)Available in 8 mm, 7 inch Tape and Reel; (5)These are Pb-Free Devices.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 NSTB1002DXV5T1 |
|
TRANSISTOR BRT NPN/PNP SOT-553 |
Data Sheet |
Negotiable |
|
||||||||||||
 |
NSTB1002DXV5T1G |
ON Semiconductor |
Transistors Switching (Resistor Biased) 100mA Complementary 50V Dual NPN & PNP |
Data Sheet |
|
|
||||||||||||
