Product Summary

The NCP15WF104J is a sized Chip NTC Thermistor. It has Ni barrier termination and provides excellent solderability and offer high stability in environment by unique inner construction.

Parametrics

NCP15WF104J absolute maximum ratings: (1)Resistance: 10 k ohm at 25℃; (2)B-Constant: 3380±3% K at 25-50℃; (3)Permissive Operating Current: 0.31mA at 25℃; (4)Rated Electric Power: 100mW at 25℃; (5)Typical Dissipation Constant: 1.0mW/℃ at 25℃; (6)Operating Temperature Range: -40 to 125℃.

Features

NCP15WF104J features: (1)Excellent solderability and high stability in environment; (2)Excellent long time aging stability; (3)High accuracy in resistance and B-constant; (4)Reflow soldering possible; (5)Lead is not contained in the product.

Diagrams

NCP15WF104J dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
NCP15WF104J03RC
NCP15WF104J03RC
Murata
Thermistors - NTC 100K OHM 5%
Data Sheet
0-1: $0.16
1-50: $0.06
50-100: $0.05
100-500: $0.04
NCP15WF104J0SRC
NCP15WF104J0SRC
Murata
Thermistors - NTC 100K OHM 5%
Data Sheet
0-1: $0.28
1-50: $0.17
50-100: $0.12
100-500: $0.08
