Product Summary

The MMSZ5232B is a 500 mW Surface Mount zener voltage regulator. It is offered in the convenient, surface mount plastic SOD-123 package. The device provides a convenient alternative to the leadless 34 package style.

Parametrics

MMSZ5232B absolute maximum ratings: (1)PD, Power Dissipation @25℃: 500 mW; (2)RθJA, Thermal Resistance, Juncion to Ambient: 340℃/W; (3)TSTG, Storage Temperature Range: -55 to +150℃; (4)TJ, Operating Junction Temperture: +150℃.

Features

MMSZ5232B features: (1)500 mW Rating on FR-4 or FR-5 Board; (2)Wide Zener Reverse Voltage Range: 2.4 V to 110 V; (3)Package Designed for Optimal Automated Board Assembly; (4)Small Package Size for High Density Applications; (5)General Purpose, Medium Current; (6)ESD Rating of Class 3 (>16 kV) per Human Body Model; (7)AEC-Q101 Qualified and PPAP Capable; (8)SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; (9)Pb-Free Packages are Available.
