Product Summary
The MC34063ADR is a 1.5A peak boost/buck/inverting switching regulator. It contains all the primary circuitry needed for building simple dc-dc converters. The MC34063ADR primarily consists of an internal temperature-compensated reference, a comparator, an oscillator, a PWM controller with active current limiting, a driver, and a high-current output switch; thus, the MC34063ADR requires minimal external components to build converters in the boost, buck, and inverting topologies.
Parametrics
MC34063ADR absolute maximum ratings: (1)Supply voltage, VCC: 40 V; (2)Comparator Inverting Input voltage range, VIR: -0.3 V to 40 V; (3)Switch Collector voltage, VC(switch): 40V; (4)Switch Emitter voltage (VPIN1 = 40 V), VE(switch) : 40V; (5)Switch Collector to Switch Emitter voltage, VCE(switch): 40V; (6)Driver Collector voltage, VC(driver): 40V; (7)Driver Collector current, IC(driver): 100 mA; (8)Switch current, ISW: 1.5 A; (9)Operating virtual junction temperature, TJ: 150℃; (10)Storage temperature range, Tstg: -65℃ to 150℃.
Features
MC34063ADR features: (1)Wide Input Voltage Range: 3 V to 40 V; (2)High Output Switch Current: Up to 1.5 A; (3)Adjustable Output Voltage; (4)Oscillator Frequency: Up to 100 kHz; (5)Precision Internal Reference: 2%; (6)Short-Circuit Current Limiting; (7)Low Standby Current.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MC34063ADR |
Texas Instruments |
DC/DC Switching Regulators 1.5-A Boost/Buck Inverting Swtch Reg |
Data Sheet |
|
|
||||||||||||
|
MC34063ADR2 |
ON Semiconductor |
Switching Converters, Regulators & Controllers 40V 1.5A |
Data Sheet |
Negotiable |
|
||||||||||||
|
MC34063ADRJR |
Texas Instruments |
DC/DC Switching Regulators 1.5A Boost/Buck/ Inverting Sw Reg |
Data Sheet |
|
|
||||||||||||
|
MC34063ADRE4 |
Texas Instruments |
DC/DC Switching Regulators 1.5-A Boost/Buck Inverting Swtch Reg |
Data Sheet |
|
|
||||||||||||
|
MC34063ADRG4 |
Texas Instruments |
DC/DC Switching Regulators 1.5A Boost/Buck/ Inverting Sw Reg |
Data Sheet |
|
|
||||||||||||
|
MC34063ADR2G |
ON Semiconductor |
Switching Converters, Regulators & Controllers 40V 1.5A Buck/Boost/Inverting |
Data Sheet |
|
|
||||||||||||
|
MC34063ADRJRG4 |
Texas Instruments |
DC/DC Switching Regulators 1.5A Boost/Buck/ Inverting Sw Reg |
Data Sheet |
|
|
||||||||||||
