Product Summary
The LM317LD is an adjustable 3-terminal positive voltage regulator capable of supplying in excess of 100 mA over an output voltage range of 1.2 V to 37 V. This voltage regulator is exceptionally easy to use and requires only two external resistors to set the output voltage. Further, it employs internal current limiting, thermal shutdown and safe area compensation, making them essentially blow–out proof. The LM317LD serves a wide variety of applications including local, on card regulation. This device can also be used to make a programmable output regulator, or by connecting a fixed resistor between the adjustment and output, the LM317LD can be used as a precision current regulator.
Parametrics
LM317LD absolute maximum ratings: (1)Input-Output Voltage Differential, VI-VO: 40 Vdc; (2)Power Dissipation, PD: Internally Limited W; (3)Operating Junction Temperature Range, TJ: -40 to +125℃; (4)Storage Temperature Range, Tstg: -65 to +150℃.
Features
LM317LD features: (1)Output Current in Excess of 100 mA; (2)Output Adjustable Between 1.2 V and 37 V; (3)Internal Thermal Overload Protection; (4)Internal Short Circuit Current Limiting; (5)Output Transistor Safe-area Compensation; (6)Floating Operation for High Voltage Applications; (7)Standard 3-lead Transistor Package; (8)Eliminates Stocking Many Fixed Voltages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM317LD |
STMicroelectronics |
Linear Regulators - Standard 1.2-37V Adj Positive |
Data Sheet |
Negotiable |
|
||||||||||||
|
LM317LD13TR |
STMicroelectronics |
Linear Regulators - Standard 1.2-37V Adj Positive |
Data Sheet |
|
|
||||||||||||
|
LM317LDR2G |
ON Semiconductor |
Linear Regulators - Standard 100mA ADJ 1.2-37V Positive |
Data Sheet |
|
|
||||||||||||
|
LM317LDG |
ON Semiconductor |
Linear Regulators - Standard 100mA ADJ 1.2-37V Positive |
Data Sheet |
|
|
||||||||||||
|
LM317LDR2 |
ON Semiconductor |
Linear Regulators - Standard 100mA ADJ 1.2-37V |
Data Sheet |
Negotiable |
|
||||||||||||
