Product Summary
The LM285MX-1.2 is a micropower 2-terminal band-gap voltage regulator diode. Operating over a 10μA to 20mA current range, it features exceptionally low dynamic impedance and good temperature stability. On-chip trimming is used to provide tight voltage tolerance. Since the LM285MX-1.2 band-gap reference uses only transistors and resistors, low noise and good long term stability result. The LM285MX-1.2 is rated for operation over a -40℃ to 85℃ temperature range.
Parametrics
LM285MX-1.2 absolute maximum ratings: (1)Reverse Current: 30mA; (2)Forward Current: 10mA; (3)Operating Temperature Range: -40℃ to +85℃; (4)Storage Temperature: -55℃ to +150℃; (5)Soldering Information: TO-92 package: 10 sec.: 260℃, TO-46 package: 10 sec.: 300℃; (6) SO and SOT Pkg.: Vapor phase (60 sec.) 215℃, Infrared (15 sec.) 220℃.
Features
LM285MX-1.2 features: (1)±4 mV (±0.3%) max. initial tolerance (A grade); (2)Operating current of 10μA to 20mA; (3)0.6W max dynamic impedance (A grade); (4)Low temperature coefficient; (5)Low voltage reference—1.235V; (6)2.5V device and adjustable device also available; (7)LM185-2.5 series and LM185 series, respectively.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM285MX-1.2 |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
 |
LM285MX-1.2/NOPB |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
