The DS1809Z-010 is a nonvolatile digitally controlled potentiometer that provides 64 uniform wiper positions over the entire resistor range; including the high-end and low-end terminals of the device. The DS1809Z-010 is a low power, low voltage device capable of operating from power supplies of +2.7V to +5.5V. The DS1809Z-010 is ideal for low-power, portable, or battery powered applications.
Parametrics
DS1809Z-010 absolute maximum ratings: (1)Voltage on Any Pin Relative to Ground: -1.0V to +7.0V; (2)Operating Temperature: -40 to +85℃; industrial; (3)Storage Temperature: -55 to +125℃; (4)Soldering Temperature: 260℃ for 10 seconds.
Features
DS1809Z-010 features: (1)64-position linear taper; (2)Two nonvolatile wiper storage options; (3)Operates from +2.7 to +5.5-volt supplies; (4)Operating Temperature Range: - Industrial: -40 to +85℃; (5)Electronic interface provides either digital or pushbutton control; (6)Low-cost alternative to mechanical solutions; (7)Standard Resistance Values.
