Product Summary
The BAT60 is a High current rectifier Schottky diode with very low VF drop.
Parametrics
BAT60 absolute maximum ratings: (1)Diode reverse voltage:10 V; (2)Forward current:3 A; (3)Non-repetitive peak surge forward current:5A; (4)Total power dissipation:1350 mW; (5)Junction temperature:150℃; (6)Operating temperature range:-55℃ to 125℃; (7)Storage temperature:-55℃ to 150℃.
Features
BAT60 features: (1)High current rectifier Schottky diode with very low VF drop(typ. 0.24 V at IF = 10mA); (2)For power supply applications; (3)For clamping and protection in low voltage applications; (4)For detection and step-up-conversion.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BAT60-08S |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
BAT60A |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
BAT60B |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
BAT60J |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
BAT60JFILM |
STMicroelectronics |
Schottky (Diodes & Rectifiers) 3.0 Amp 10 Volt |
Data Sheet |
|
|
||||||||||||
