AP34063N8L-U

universal DC/DC converter, 40 V, 1.6 A, 1.25 W, 8DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.42~0.42 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.42~0.42

PartNumber:: AP34063N8L-U

Brand:: Anachip - Diodes | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:AP34063N8L-U
US $0.42 - 0.42
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AP34063N8L-U is a monolithic control circuit containing the primary functions required for DC-to-DC converter. The AP34063N8L-U consists of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. The AP34063N8L-U is specifically designed for incorporating in Step-Down and Step-Up and Voltage-Inverting applications with a minimum number of external components.

Parametrics

AP34063N8L-U absolute maximum ratings: (1)Power Supply Voltage VCC: 40 V; (2)Comparator Input Voltage Range VIR: -0.3 ~ +40 V; (3)Switch Collector Voltage VC (switch): 40 V; (4)Switch Emitter Voltage (VPin 1 = 40V)VE (switch): 40 V; (5)Switch Collector to Emitter Voltage VCE (switch): 40 V; (6)Driver Collector Voltage VC (driver): 40 V; (7)Driver Collector Current IC (driver): 100 mA; (8)Switch Current ISW: 1.6 A; (9)Power Dissipation SOP: TA = 25℃ PD: 600 mW; (10)Power Dissipation PDIP: TA = 25℃ PD: 1.25 W; (11)Maximum Junction Temperature TMJ: +150 ℃; (12)Operating Junction Temperature Range TOP: 0 ~ +105 ℃; (13)Storage Temperature Range Tstg: -65 ~ +150 ℃.

Features

AP34063N8L-U features: (1)Operation from 3.0V to 40V Input; (2)Low Standby Current; (3)Current Limiting; (4)Output Switch Current to 1.6A; (5)Output Voltage Adjustable; (6)Frequency Operation to 100 kHz; (7)Precision 2% Reference; (8)8-pin SOP, PDIP package.
