ADM208ANZ

line driver/receiver, DIP24, 0.1 μF to 10 μF, ±9 V, 15 mW, ADM208ANZ

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.26~1.27 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.26~1.27

PartNumber:: ADM208ANZ

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-13

From Other Seller

Part Number:ADM208ANZ
US $1.26 - 1.27
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ADM208ANZ line driver/receiver is intended for all EIA-232-E and V.28 communications interfaces, especially in applications where ±12 V is not available. The ADM208ANZ features a low power shutdown mode which reduces power dissipation to less than 5 μW making them ideally suited for battery powered equipment. It does not require any external components and is particularly useful in applications where printed circuit board space is critical. The ADM208ANZ has an active-low shutdown and an active-high receiver enable control. The applications of the ADM208ANZ include Computers, Peripherals, Modems, Printers, Instruments.

Parametrics

ADM208ANZ absolute maximum ratings: (1)VCC: –0.3 V to +6 V; (2)V+: (VCC – 0.3 V) to +14 V; (3)V–:. +0.3 V to –14 V; (4)Input Voltages: TIN: –0.3 V to (VCC + 0.3 V), RIN: ±30 V; (5)Output Voltages: TOUT: (V+, + 0.3 V) to (V–, –0.3 V), ROUT: –0.3 V to (VCC + 0.3 V); (6)Short Circuit Duration TOUT: Continuous Power Dissipation.

Features

ADM208ANZ features: (1)0.1 μF to 10 μF Capacitors; (2)120 kB/s Data Rate; (3)On-Board DC-DC Converters; (4)±9 V Output Swing with +5 V Supply; (5)Low Power (15 mW); (6)Low Power Shutdown ≤5 μW; (7)±30 V Receiver Input Levels; (8)Latch-Up FREE; (9)Plug-In Upgrade for MAX205-211/213.
