Product Summary

The AD8620 is a very high precision JFET input amplifier featuring ultralow offset voltage and drift, very low input voltage and current noise, very low input bias current, and wide bandwidth. Unlike many JFET amplifiers, the AD8620 input bias current is low over the entire operating temperature range. The AD8620 is stable with capacitive loads of over 1000 pF in noninverting unity gain; much larger capacitive loads can be driven easily at higher noise gains. The AD8620 swings to within 1.2 V of the supplies even with a 1 kΩ load, maximizing dynamic range even with limited supply voltages. Outputs slew at 50 V/μs in either inverting or noninverting gain configurations, and settle to 0.01% accuracy in less than 600 ns.

Parametrics

AD8620 absolute maximum ratings: (1)Supply Voltage: 27.3 V; (2)Input Voltage: VS to VS+; (3)Differential Input Voltage: ± Supply Voltage; (4)Output Short-Circuit Duration to GND: Indefinite; (5)Storage Temperature Range R, RM Packages: –65℃ to +150℃; (6)Operating Temperature Range: –40℃ to +125℃; (7)Junction Temperature Range R, RM Packages: –65℃ to +150℃; (8)Lead Temperature Range (Soldering, 10 sec): 300℃.

Features

AD8620 features: (1)Low Noise 6 nV/√Hz; (2)Low Offset Voltage: 100μV Max; (3)Low Input Bias Current 10 pA Max; (4)Fast Settling: 600 ns to 0.01%; (5)Low Distortion; (6)Unity Gain Stable; (7)No Phase Reversal; (8)Dual-Supply Operation: ±5 V to ±13 V.
