93LC46B/SN

93LC46B/SN, 1K bit, EEPROM, 2MHZ, 8SOIC, 7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.12~0.12 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.12~0.12

PartNumber:: 93LC46B/SN

Brand:: Anachip - Diodes | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:93LC46B/SN
US $0.12 - 0.12
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 93LC46B/SN is a 1K bit low voltage serial Electrically Erasable PROM (EEPROM). For dedicated 8-bit communication, the 93LC46B/SN provide dedicated 16-bit communication. Advanced CMOS technology makes the device ideal for low power, nonvolatile memory applications. The 93LC46B/SN is available in standard packages including 8-lead PDIP and SOIC, and advanced packaging including 8-lead MSOP, 6-lead SOT-23, and 8-lead TSSOP. Pb-free (Pure Matte Sn) finish is also available.

Parametrics

93LC46B/SN absolute maximum ratings: (1)VCC: 7.0V; (2)All inputs and outputs w.r.t. VSS: -0.6V to VCC +1.0V; (3)Storage temperature: 65 to +150℃; (4)Ambient temperature with power applied: -40 to +125℃; (5)ESD protection on all pins: ≥ 4 kV.

Features

93LC46B/SN features: (1)Low-power CMOS technology; (2)ORG pin to select word size for 46C version; (3)128 x 8-bit organization A ver. devices (no ORG); (4)64 x 16-bit organization A ver. devices (no ORG); (5)Self-timed ERASE/WRITE cycles (including auto-erase); (6)Automatic ERAL before WRAL; (7)Power-on/off data protection circuitry; (8)Industry standard 3-wire serial I/O; (9)Device Status signal (READY/BUSY); (10)Sequential READ function; (11)1,000,000 E/W cycles; (12)Data retention > 200 years; (13)Temperature ranges supported.
