The 74LS04 is a HEX inverter.
Parametrics
74LS04 absolute maximum ratings: (1)VCC Supply Voltage: 4.75 to 5.25V, 5.0V typ; (2)TA, Operating Ambient Temperature Range: 0 to 70℃; 25℃ typ; (3)IOH Output Current — High: –0.4 mA; (4)IOL Output Current — Low: 8.0 mA.
Features
74LS04 features: (1)tPLH, Turn-Off Delay, Input to Output: 9.0ns typ, 15 ns max; (2)tPHL, Turn-On Delay, Input to Output: 10ns typ, 15 ns max.
