Product Summary

The SN74LS04DR is a HEX inverter.

Parametrics

SN74LS04DR absolute maxing ratings: (1)Supply voltage VCC: 7V; (2)Input voltage: 7V; (3)Package thermal impedance, θJA: D package: 86℃/W; DB package: 96℃/W; N package: 80℃/W; NS package: 76℃/W; (4)Storage temperature range: -65℃ to 150℃.

Features

SN74LS04DR features: Dependable Texas Instruments Quality and Reliability.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SN74LS04DR
SN74LS04DR

Texas Instruments

Inverters HEX INVERTERS

Data Sheet

0-1: $0.35
1-25: $0.32
25-100: $0.27
100-250: $0.24
SN74LS04DRE4
SN74LS04DRE4

Texas Instruments

Inverters HEX INVERTERS

Data Sheet

0-1: $0.35
1-25: $0.32
25-100: $0.27
100-250: $0.24
SN74LS04DRG4
SN74LS04DRG4

Texas Instruments

Inverters HEX INVERTERS

Data Sheet

0-1: $0.35
1-25: $0.28
25-100: $0.25
100-250: $0.22
