Product Summary

The SN74LS02DR is a quadruple 2-input Positive-NOR gate. The SN74LS02DR contains four independent 2-input-NOR gates. The SN74LS02DR is characterizes for operation over the full military temperature range of -55℃ to 125℃

Parametrics

SN74LS02DR absolute maximum ratings: (1)supply voltage VCC: 7V; (2)input voltage : 7V; (3)off-state output voltage: 7V; (4)operating free-air temperature range: 0℃ to 70℃; (5)storage temperature range: -65℃ to 150℃.

Features

SN74LS02DR features: (1) Package Options include plastic "small outline" packages, ceramic chip carriers and flat packages, and plastic and ceramic DIPs; (2) Dependable texas instruments quality and reliability.

Diagrams

SN74LS02DR block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74LS02DR
SN74LS02DR
Texas Instruments
Gates (AND / NAND / OR / NOR) Quad 2-input Positive-NOR gates
Data Sheet
0-1: $0.32
1-25: $0.29
25-100: $0.25
100-250: $0.22
SN74LS02DRE4
SN74LS02DRE4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quad 2-input Positive-NOR gates
Data Sheet
0-1: $0.32
1-25: $0.26
25-100: $0.23
100-250: $0.20
SN74LS02DRG4
SN74LS02DRG4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quad 2 input pos NOR gates
Data Sheet
0-1: $0.32
1-25: $0.26
25-100: $0.23
100-250: $0.20
