SCA620-CF8H1A

SCA620-CF8H1A, SOP8, 1-AXIS ANALOG ACCELEROMETER, -0.3V to 7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.52~9.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $9.52~9.60

PartNumber:: SCA620-CF8H1A

Brand:: VTI technologies - VTI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-06

From Other Seller

Part Number:SCA620-CF8H1A
US $9.52 - 9.60
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SCA620-CF8H1A is a one axis accelerometer component based on proven VTI capacitive 3D-MEMS technology. It has exceptional reliability, unprecedented accuracy and excellent stability over temperature and time. The SCA620-CF8H1A is designed, manufactured for high stability and reliability and tested against tough quality requirements of automotive applications. The accelerometer has outstanding overload and shock durability. There is no need for additional components. The SCA620-CF8H1A is a part of VTI analog accelerometer family and fully compatible with other SCA610 and SCA620 - series accelerometers. The applications of the SCA620-CF8H1A include Acceleration measurement, Inclination measurement, Motion measurement, Vibration measurement.

Parametrics

SCA620-CF8H1A absolute maximum ratings: (1)Supply voltage: -0.3V to 7.0V; (2)Voltage to input/output pins: -0.3V to VDD + 0.3V; (3)Temperature range: -40℃ to +125℃; (4)Mechanical shock: 20000g.

Features

SCA620-CF8H1A features: (1)Single +5 V supply; ratiometric voltage output in the range 4.75V to 5.25V; (2)±1.7g Range; (3)8-pin plastic surface mount package with gull wing legs, mountable with pick and place machine; (4)Enhanced failure detection; (5)Digitally activated electrostatic self test; (6)Calibration memory parity check; (7)Continuous connection failure detection; (8)Bi-directional acceleration measurement; (9)Controlled frequency response in the sensing element; (10)RoHS compliant suitable for lead free soldering process and SMD mounting; (11)Proven capacitive 3D-MEMS technology.
