Product Summary

The MRF7S38075HR3 is a RF power field effect transistor designed for WiMAX base station applications with frequencies up to 3800 MHz. Suitable for WiMAX, WiBro, BWA, and OFDM multicarrier Class AB and Class C amplifier applications.

Parametrics

MRF7S38075HR3 absolute maximum ratings: (1)Drain-Source Voltage VDS: -0.5, +65 Vdc; (2)Gate-Source Voltage VGS: -6.0, +10 Vdc; (3)Operating Voltage VDD: 32, +0 Vdc; (4)Storage Temperature Range Tstg: - 65 to +150 ℃; (5)Case Operating Temperature TC: 150 ℃; (6)Operating Junction Temperature TJ: 225 ℃.

Features

MRF7S38075HR3 features: (1)Characterized with Series Equivalent Large-Signal Impedance Parameters; (2)Internally Matched for Ease of Use; (3)Integrated ESD Protection; (4)Greater Negative Gate-Source Voltage Range for Improved Class C Operation; (5)RoHS Compliant; (6)In Tape and Reel. R3 Suffix = 250 Units per 56 mm, 13 inch Reel.

Diagrams

MRF7S38075HR3 pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MRF7S38075HR3
MRF7S38075HR3

Freescale Semiconductor

Transistors RF MOSFET Power 3600MHZ 12W 30V NI780H

Data Sheet

0-188: $55.05
188-250: $55.05
