Product Summary

The H5004T is a 1000BASE-T magnetics module Designed to Support 1:1 Turns Ratio Transceivers.

Parametrics

H5004T absolute maximum ratings: (1)Number of Ports: 1; (2)Insertion Loss: 1dB; (3)Hipot: 1500 VRMS MIN.

Features

H5004T features: (1)RoHS-5 peak reflow temperature rating 235℃; (2)RoHS-6 peak reflow temperature rating 245℃; (3)Meets IEEE 802.3 specification.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
H5004T
H5004T
Pulse
Transformers Audio & Signal 24-PIN SOIC
Data Sheet
0-178: $5.06
178-300: $5.06
300-500: $4.14
500-1000: $3.83
