AD8182AR-REEL7

AD, 750 MHz, 3.8 mA, 10 ns Switching Multiplexers, 12.6V, 1.0Watts, 14SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.46~1.46 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.46~1.46

PartNumber:: AD8182AR-REEL7

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-10-09

From Other Seller

Part Number:AD8182AR-REEL7
US $1.46 - 1.46
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
LM285M-2.5

US $0.16 - 0.25 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD8182AR-REEL7 is a high speed 2-to-1 multiplexer. The AD8182AR-REEL7 offers –3 dB signal bandwidth greater than 750 MHz along with slew rate of 750 V/ms. With better than 80 dB of crosstalk and isolation, The AD8182AR-REEL7 is useful in many high speed applications. The differential gain and differential phase error of 0.02% and 0.02°, along with 0.1 dB flatness beyond 100 MHz make the AD8180 and AD8182 ideal for professional video multiplexing. The AD8182AR-REEL7 offers 10 ns switching time making them an excellent choice for pixel switching (picture-in-picture) while consuming less than 3.8 mA (per 2:1 mux) on ±5 V supply voltages. The applications of the AD8182AR-REEL7 are Pixel Switching for “Picture-In-Picture”, Switching in LCD and Plasma Displays, Video Switchers and Routers.

Parametrics

AD8182AR-REEL7 absolute maximum ratings: (1)Supply Voltage:12.6 V; (2)Internal Power Dissipation2;:1.0 Watts; (3)Input Voltage:±VS; (4)Output Short Circuit Duration: Observe Power Derating Curves; (5)Storage Temperature Range; (6)N and R Package:–65℃to +125℃; (7) Lead Temperature Range (Soldering 10 sec): +300℃.

Features

AD8182AR-REEL7 features: (1)Fully Buffered Inputs and Outputs; (2)Fast Channel Switching: 10 ns; (3)High Speed; (4)＞750 MHz Bandwidth (–3 dB); (5)750 V/ms Slew Rate; (6)Fast Settling Time of 14 ns to 0.1%; (7)Low Power:6.8 mA; (8)Excellent Video Specifications (RL≥1 kΩ); (9)Gain Flatness of 0.1 dB Beyond 100 MHz; (10)0.02% Differential Gain Error; (11)0.028 Differential Phase Error; (12)Low Glitch: ＜35 mV; (13)Low All-Hostile Crosstalk of –80 dB @ 5 MHz; (14)High “OFF” Isolation of –90 dB @ 5 MHz; (15) Low Cost; (16) Fast Output Disable Feature for Connecting Multiple Devices.
