AD8002AR

AD, Dual 600 MHz, 50 mW Current Feedback Amplifier, sop-8, 12.6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.26~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.26~1.30

PartNumber:: AD8002AR

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ella Wu's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-21

From Other Seller

Part Number:AD8002AR
US $1.26 - 1.30
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD8002AR is a dual, low power, high speed amplifier designed to operate on ±5 V supplies. The AD8002AR features unique transimpedance linearization circuitry. This allows it to drive video loads with excellent differential gain and phase performance on only 50 mW of power per amplifier. The AD8002AR is a current feedback amplifier and features gain flatness of 0.1 dB to 60 MHz while offering differential gain and phase error of 0.01% and 0.02°. This makes the AD8002AR ideal for professional video electronics such as cameras and video switchers. Additionally, the AD8002AR’s low distortion and fast settling make it ideal for buffer high speed A-to-D converters. The applications of the AD8002AR are A-to-D Driver, Video Line Driver, Differential Line Driver, Professional Cameras, Video Switchers, Special Effects, RF Receivers.

Parametrics

AD8002AR absolute maximum ratings: (1)Supply Voltage: 12.6 V; (2)Internal Power Dissipation: Plastic DIP Package (N): 1.3W, Small Outline Package (R): 0.9W, μSOIC Package (RM): 0.6W; (3)Input Voltage (Common Mode): ±VS; (4)Differential Input Voltage: ±1.2 V; (5)Output Short Circuit Duration: Observe Power Derating Curves; (6)Storage Temperature Range N, R, RM: –65℃ to +125℃; (7)Operating Temperature Range (A Grade): –40℃ to +85℃; (8)Lead Temperature Range (Soldering 10 sec): +300℃.
