Product Summary
The AD7816ARZ is a Single- and 4-Channel, 9μs, 10-Bit ADC with On-Chip Temperature Sensor. It is a temperature monitoring only device in a SOIC/MSOP package. The AD7816ARZ has a flexible serial interface that allows easy interfacing to most microcontrollers. The applications of the AD7816ARZ include: Ambient Temperature Monitoring: Thermostat and Fan Control, High Speed Microprocessor, Temperature Measurement and Control; Data Acquisition Systems with Ambient Temperature: Industrial Process Control, Automotive, Battery Charging Applications.
Parametrics
AD7816ARZ absolute maximum ratings: (1)VDD to AGND: –0.3 V to +7 V; (2)VDD to DGND: –0.3 V to +7 V; (3)Analog Input Voltage to AGND VIN1 to VIN4: –0.3 V to VDD + 0.3 V; (4)Reference Input Voltage to AGND: –0.3 V to VDD + 0.3 V; (5)Digital Input Voltage to DGND: –0.3 V to VDD + 0.3 V; (6)Digital Output Voltage to DGND: –0.3 V to VDD + 0.3 V; (7)Storage Temperature Range: –65℃ to +150℃; (8)Junction Temperature: 150℃; (9)TSSOP, Power Dissipation: 450 mW.
Features
AD7816ARZ features: (1)10-Bit ADC with 9 μs Conversion Time; (2)One (AD7818) and Four (AD7817) Single-Ended Analog Input Channels; (3)The AD7816 Is a Temperature Measurement Only Device On-Chip Temperature Sensor; (4)Wide Operating Supply Range 2.7 V to 5.5 V; (5)Inherent Track-and-Hold Functionality; (6)On-Chip Reference (2.5 V ± 1%); (7)Overtemperature Indicator; (8)Automatic Power-Down at the End of a Conversion; (9)Low Power Operation; (10)Flexible Serial Interface.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD7816ARZ |
Analog Devices Inc |
IC ADC 10BIT W/TEMP SNSR 8SOIC |
Data Sheet |
Negotiable |
|
||||
|
AD7816ARZ-REEL |
Analog Devices Inc |
IC ADC 10BIT W/TEMP SNSR 8SOIC |
Data Sheet |
Negotiable |
|
||||
|
AD7816ARZ-REEL7 |
Analog Devices Inc |
IC ADC 10BIT W/TEMP SNSR 8SOIC |
Data Sheet |
Negotiable |
|
||||
