The 6N136 is an optocoupler. It consists of an AlGaAs LED optically coupled to a high speed photodetector transistor.
Parametrics
6N136 absolute maximum ratings: (1)TSTG, Storage Temperature: -55 to +125℃; (2)TOPR, Operating Temperature: -55 to +100℃; (3)TSOL, Lead Solder Temperature: 260℃ for 10 sec; (4)VR, Reverse Input Voltage Each Channel: 5 V.
Features
6N136 features: (1)High speed–1MBit/s; (2)Superior CMR-10kV/μs; (3)Dual-Channel HCPL-2530/HCPL-2531; (4)Double working voltage–480V RMS; (5)CTR guaranteed 0–70℃; (6)U.L. recognized (File # E90700).
