Product Summary
The EP2C20F484C7NK is a differnetial interface standard requipring a 3.3V VCCIO and is used in applications involving video graphics, telecommunications, data communications, and clock distribution. The high speed, low voltage swing LVPECL I/O standard uses a positive poer supply and is similar to LVDS.
Parametrics
EP2C20F484C7NK absolute maximum ratings: (1)VCCINT, supply voltage: 1.15 to 1.25V; 1.2V typ; (2)VCCIO, I/O supply voltage: 2.375 to 2.625V, 2.5V typ; (3)VOD, differential output voltage: 247 to 600mV; (4)△VOD, change in VOD betweent: 50mV; (5)VOS, output offset voltage: 1.125 to 1.375V, 1.25V typ.
Features
EP2C20F484C7NK features: (1)longer traces have more inductance and capacitance; (2)use surface mount components; (3)use high performance connectors; (4)keep equal number of vias for both signal traces; (5)limit vias because they cause discontinuities.
Diagrams
 |
