Product Summary
The 74AHCT245PW is a high-speed Si-gate CMOS device. It is an octal transceiver featuring non-inverting 3-state bus compatible outputs in both send and receive directions. The 74AHCT245PW features an Output Enable (OE) input for easy cascading and a send/receive (DIR) input for direction control. OE controls the outputs so that the buses are effectively isolated.
Parametrics
74AHCT245PW absolute maximum ratings: (1)supply voltage:-0.5V to +7.0V; (2)input voltage:-0.5V to +7.0V; (3)input clamping current:-20mA; (4)output clamping current:±20mA; (5)output current:±25mA; (6)supply current:75mA; (7)ground current:-75mA; (8)storage temperature:-65℃ to +150℃; (9)total power dissipation Tamb = -40℃ to +125℃:500 mW.
Features
74AHCT245PW features: (1)Balanced propagation delays; (2)All inputs have a Schmitt-trigger action; (3)Inputs accepts voltages higher than VCC; (4)For 74AHCT245 only: operates with TTL input levels; (5)ESD protection:HBM JESD22-A114E exceeds 2000 V,MM JESD22-A115-A exceeds 200 V,CDM JESD22-C101C exceeds 1000 V; (6)Multiple package options; (7)Specified from -40℃ to +85℃ and from -40℃ to +125℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 74AHCT245PW |
NXP Semiconductors |
Bus Transceivers OCTAL TRANSCVR 3-S |
Data Sheet |
Negotiable |
|
||||||||||||||||||||||
 |
74AHCT245PW,112 |
|
IC TRANSCVR TRI-ST 8BIT 20TSSOP |
Data Sheet |
|
|
||||||||||||||||||||||
 |
74AHCT245PW,118 |
NXP Semiconductors |
Bus Transceivers OCTAL TRANSCVR 3-S |
Data Sheet |
|
|
||||||||||||||||||||||
